Signal Generator GAM 300 N ver E DUAL

Description:

Signal generators of the GAM300 N ver E series are high quality devices generating warning sounds in special and privileged vehicles.

The GAM300 N ver E series is optimized for use in emergency vehicles of the Police and Ambulance.

Basic features of GAM300 N ver E:

- Dedicated to 12V or 24V car installations,

- Low power consumption in standby (approx. 30mA),

- 2 x 100W active output power,

- Five relay outputs (Channels A, B, C, D, E),

- Horn signal control (option on the + battery side or vehicle weight),

- Two universal inputs, controlled by the vehicle mass signal available for user,

- Six standard signaling tones: WAIL, YELP, HI-LO, and others plus HORN

- The dimensions of the amplifier 175x189x59 mm, the dimensions of the manipulator 49x109x25 mm,

- Manipulator cable length: 4.5m (2.5m standard),

- Work with speakers with a rated impedance of 11 ohm

- Compliance with UNECE regulations R10

Interesting usable functions of GAM300 N ver R:

- The ability to turn off the keypad backlight,

- Possibility of working with half of the usable power (so-called night mode),

- Possibility to choose the method of controlling the D channel (bistable, astable),

- Possibility to choose the scenario (three types) of control via the vehicle horn.

We produced models:

GAM300 N v E 12V / 2x100W, for 12V installations / Index number: 02.301

GAM300 N v E 24V / 2x100W, for 24V installations / Index number: 02.401
